• Material: AiSi 316 / A4
Product Image 1
Select a row from the table below, then click the add to quote button
Part Code Rope diameter
mm
weight per 100 pcs.
kg
units per bag A
mm
C
mm
l
mm
10.2690043323 2,5 0,2 50 3 10 15
10.2690044427 3,5 0,3 50 4 11 17
10.2690045532 4 0,4 50 5 13 21
10.2690046639 5 0,7 50 6 16 26
10.2690047742 6 0,8 50 7 18 29
10.2690048850 7 1,2 25 8 20 32
10.2690049105 9 3,2 25 10 26 42
10.2690050128 11 4,1 10 12 28 43
10.2690050140 13 6,1 10 14 34 58
10.2690050160 15 9,4 10 16 37 60
10.2690050180 16 11,3 10 18 42 66
10.2690050200 18 17,2 10 20 45 79
