AW Master links are designed for the assembly of chain slings. For pewag connex and welded system.
Master link for 1-leg chain AI.
Master link for 2-leg chain AII.
Master link for 3- and 4-leg chain AIII/IV - only with transition link BW as on VW.
Can also be used as end link A I
- Material: High duty
- Marking: According to standard, CE-marked, Pewag or PW, winner or 10, H16, batch code and type.
- Temperature range: -40ºC up to +380°C.
- Finish: Orange powder coated.
- Standard: EN 1677-4
- Safety factor: 4:1
- Grade: 10
Download CAD by choosing the desired product from the table above and the format from the menu below. Click "Get CAD" and after the load reaches 100% you can click on the download icon to download it. Please note that CAD drawings are only available if the icon at the right side of the table above is colored and not grayed out.
To download CAD files, you must provide a valid e-mail address
