Casar
  • Ordinary right hand lay
  • Ordinary left hand lay
  • Bright
  • Galvanized
  • Compacted strands
  • Double parallel lay construction
  • Swaged
  • Not to be used with swivel

Advantages and features:
- Extremely high breaking strength
- Very stabile wire rope construction with good fatigue properties
- A plastic layer between inner and outer strands prevents inner wear and protects the core from corrosion.
- Very high resistance against flattening and wear.
- Especially suitable for multiple layer spooling.
ISO 4309 Rope Category No: 8-50mm RCN.09,

  • Rope construction: 8 strand hammered rope in parallel lay construction made out of compacted outer strands. Has a plastic layer between the steel core and the outer strands, giving the rope a high structural s
  • Marking: According to standard
  • Standard: EN 12385-4
  • Fill factor: 0.74
  • Offshore crane
  • Crawler crane
Parafit[new]_225mm
Parafit
Offshore crane Offshore crane Boom hoist rope
Select a row from the table below, then click the add to quote button
Part Code Diameter
mm
Steel Area
mm²
Min. breakingforce
kN
1960 N/mm²
Min. breakingforce
kN
2160 N/mm²
Weight
kg/100m
01.B13CPF080G 8 37 63.1 68.7 29
01.B13CPF090G 9 46.6 79.4 86.5 37
01.B13CPF100G 10 57.1 97.3 106 49
01.B13CPF110G 11 71.2 121 132 55
01.B13CPF120G 12 82.7 141 154 65
01.B13CPF130G 13 97.9 167 182 77
01.B13CPF140G 14 115 196 213 89
01.B13CPF150G 15 131 223 243 102
01.B13CPF160G 16 150 255 278 117
01.B13CPF170G 17 171 292 318 132
01.B13CPF180G 18 189 323 352 146
01.B13CPF190G 19 214 364 397 163
01.B13CPF200G 20 234 398 434 181
01.B13CPF210G 21 257 437 477 198
01.B13CPF220G 22 285 485 529 220
01.B13CPF230G 23 310 528 576 240
01.B13CPF240G 24 338 576 628 261
01.B13CPF250G 25 366 624 680 282
01.B13CPF260G 26 394 672 732 307
01.B13CPF280G 28 459 783 853 353
01.B13CPF300G 30 529 902 983 410
01.B13CPF320G 32 598 1,019 1,110 464
01.B13CPF340G 34 679 1,157 1,261 523
01.B13CPF360G 36 758 1,292 1,407 583
01.B13CPF380G 38 848 1,446 1,576 655
01.B13CPF400G 40 935 1,594 1,736 729
Other dimensions and tensile grade on request.
