Ropeblock




  • Features: Spelter socket generates the wirerope breaking load 100%.
  • Material: High-strength steel.
  • Finish: Galvanized or painted blue.
Closed Spelter Socket_pic_opeblock
Closed Spelter Socket_dwg_Ropeblock
Select a row from the table below, then click the add to quote button
Part Code Code MBL
t
Finish Diameter
mm
TL
mm
TA
mm
A
mm
B
mm
C
mm
√ė H
mm
K
mm
T
mm
Weight
kg
CAD
10.10CSS296.GAL CSS 296 8 G 6-7 101 37 50 40 11 9,1 22 13 0.3
10.10CSS297.GAL CSS 297 12 G 8-10 119 43 57 48 14 12,6 25 18 0.5
10.10CSS298.GAL CSS 298 20 G 11-13 140 51 64 59 17,5 14,6 30 23 0.7
10.10CSS299.GAL CSS 299 25 G 14-16 162 67 76 65 21 18,1 36 26 1.4
10.10CSS200.GAL CSS 200 40 G 18-19 194 76 89 78 27 21,9 42 32 2.2
10.10CSS201.GAL CSS 201 55 G 20-22 224 92 101 90 33 24,9 47 38 3.8
10.10CSS204.GAL CSS 204 75 G 23-26 253 104 114 103 36 28,8 57 44 5.4
10.10CSS207.GAL CSS 207 90 G 27-30 282 114 127 116 39 32,9 65 51 7
10.10CSS212.GAL CSS 212 125 G 31-36 312 126 139 130 43 39,2 71 57 10
10.10CSS215.GAL CSS 215 150 G 37-39 358 136 152 155 51 42,5 81 63 13
10.10CSS217.GAL CSS 217 170 G 40-42 390 146 165 171 54 45,5 83 70 17
10.10CSS219.GAL CSS 219 225 G 43-48 443 171 190 198 55 52,5 93 76 26
10.10CSS222.GAL CSS 222 280 G 49-54 502 193 216 224 62 59,1 100 82 37
10.10CSS224.GAL CSS 224 360 G 55-60 548 216 228 247 73 65,1 112 92 50
10.10CSS226.GAL CSS 226 425 G 61-68 257 241 248 270 79 73,4 140 102 66
10.10CSS227.GAL CSS 227 460 G 69-75 644 273 279 286 79 79,4 159 124 91
10.10CSS228.GAL CSS 228 560 G 76-80 696 292 315 298 83 88,2 171 133 117
10.10CSS229.GAL CSS 229 625 G 81-86 743 311 330 311 102 92,4 184 146 125
10.10CSS230.GAL CSS 230 720 G 87-93 788 330 356 330 102 98,8 197 159 176
10.10CSS231.GAL CSS 231 875 G 94-102 845 362 381 356 108 107,8 216 178 228
10.10CSS233.GAL CSS 233 1,200 G 108-115 1,000 405 450 425 125 129,5 235 190 323
10.10CSS240.GAL CSS 240 1,400 G 120-130 1,150 450 500 525 125 147,1 260 200 447
10.10CSS245.GAL CSS 245 1,600 G 135-140 1,185 520 540 495 150 153,9 290 220 645
10.10CSS250.GAL CSS 250 2,000 G 142-153 1,285 545 585 530 170 171,1 305 240 741
10.10CSS255.GAL CSS 255 2,220 G 154-165 1,370 575 630 565 175 185,1 330 250 860
10.10CSS260.GAL CSS 260 2,500 G 166-178 1,450 595 680 590 180 199,1 330 270 985
10.10CSS265.GAL CSS 265 2,800 G 180-191 1,535 625 725 620 190 213 350 290 1,183
10.10CSS270.GAL CSS 270 3,200 G 192-204 1,635 690 775 650 210 228,5 395 305 1,487

Finish G = galvanized

Finish P = painted RAL 5013 blue
