Welded Master Link Assembly Crosby A-1346

Home / Products / Lifting equipment / COMPONENTS / Master links and Connectors / Welded Master Link Assembly Crosby A-1346

Features:

Ratings below are for use with chain slings fabricated in accordance with ASTM B30.9.
Individually Proof Tested to values shown.
Meets or exceed all requirements of ASME B30.26 including identification, ductility, design factor, proof load and temperature requirements. Importantly, this master link meet other critical performance requirements including fatique life, impact properties and material traceability, not addressed by ASME B30.26.

Material: Alloy Steel - Quenched and Tempered.
Marking: Code and grade
Finish: Painted

Safety factor: 4:1
Grade: 10

Select a row from the table below, then click the add to quote button

Part Code	WLL ton	Chain G80 3 and 4 legs	Chain G100 3 and 4 legs	A mm	B mm	C mm	D mm	E mm	F mm	Weight kg
11.021256868	4.1	7	6	17	90	160	13	60	120	1.58
11.021256874	4.3	8	7	19	90	160	13	60	120	1.8
11.021256883	6.7	10	8	22	100	180	17	90	160	3.35
11.021256892	8.9	10	10	25	146	275	19	90	160	5.51
11.021256917	14.5	13	13	28	145	275	22	100	180	7.17
11.021256926	17	16	13	31	145	275	25	115	210	9.72
11.021256935	23.6	18-19	16	36	146	275	28	100	190	12.2
11.021256944	28.1	19-20	18	40	160	300	31	145	275	18.68
11.021256953	38.3	22-23	19-20	45	180	340	36	155	285	26.56
11.021256962	45	26	22-23	50	200	380	38	140	370	32.86
11.021256971	67	32	26	57	203	406	50	200	380	59.7
11.021256	98.4		32	70	251	457	70	251	457	88.9

Download CAD

Download CAD by choosing the desired product from the table above and the format from the menu below. Click "Get CAD" and after the load reaches 100% you can click on the download icon to download it. Please note that CAD drawings are only available if the icon at the right side of the table above is colored and not grayed out.

Get CAD

Download
